Atik SDK C interface header. More...

#include <stddef.h>
#include <stdbool.h>

Classes
struct	ARTEMISPROPERTIES

Macros
#define	artfn extern
	Function declaration linkage is implicitly extern This definition and further usage has been left in for legacy purposes.

Typedefs
typedef int	BOOL
	Typedef for non windows builds.

typedef void *	HINSTANCE
	Typedef for non windows builds.

typedef void *	ArtemisHandle

Enumerations
enum	ARTEMISERROR { ARTEMIS_OK = 0 , ARTEMIS_INVALID_PARAMETER , ARTEMIS_NOT_CONNECTED , ARTEMIS_NOT_IMPLEMENTED , ARTEMIS_NO_RESPONSE , ARTEMIS_INVALID_FUNCTION , ARTEMIS_NOT_INITIALIZED , ARTEMIS_OPERATION_FAILED }
	Main error enum for methods with "int" as return type. More...

enum	ARTEMISCOLOURTYPE { ARTEMIS_COLOUR_UNKNOWN = 0 , ARTEMIS_COLOUR_NONE , ARTEMIS_COLOUR_RGGB }
	Camera colour properties. More...

enum	ARTEMISPRECHARGEMODE { PRECHARGE_NONE = 0 , PRECHARGE_ICPS , PRECHARGE_FULL }

enum	ARTEMISCAMERASTATE { CAMERA_ERROR = -1 , CAMERA_IDLE = 0 , CAMERA_WAITING , CAMERA_EXPOSING , CAMERA_READING , CAMERA_DOWNLOADING , CAMERA_FLUSHING }

enum	ARTEMISCONNECTIONSTATE { CAMERA_CONNECTING = 1 , CAMERA_CONNECTED = 2 , CAMERA_CONNECT_FAILED = 3 , CAMERA_SUSPENDED = 4 , CAMERA_CONNECT_UNKNOWN = 5 }

enum	ARTEMISPROCESSING { ARTEMIS_PROCESS_LINEARISE = 1 , ARTEMIS_PROCESS_VBE = 2 }

enum	ARTEMISPROPERTIESCCDFLAGS { ARTEMIS_PROPERTIES_CCDFLAGS_INTERLACED = 1 , ARTEMIS_PROPERTIES_CCDFLAGS_DUMMY = 0x7FFFFFFF }
	Index into the ccdflags value of ARTEMISPROPERTIES. More...

enum	ARTEMISPROPERTIESCAMERAFLAGS { ARTEMIS_PROPERTIES_CAMERAFLAGS_FIFO = 1 , ARTEMIS_PROPERTIES_CAMERAFLAGS_EXT_TRIGGER = 2 , ARTEMIS_PROPERTIES_CAMERAFLAGS_PREVIEW = 4 , ARTEMIS_PROPERTIES_CAMERAFLAGS_SUBSAMPLE = 8 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_SHUTTER = 16 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_GUIDE_PORT = 32 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_GPIO = 64 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_WINDOW_HEATER = 128 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_EIGHT_BIT_MODE = 256 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_OVERLAP_MODE = 512 , ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_FILTERWHEEL = 1024 , ARTEMIS_PROPERTIES_CAMERAFLAGS_DUMMY = 0x7FFFFFFF }

enum	ARTEMISCOOLINGINFO { ARTEMIS_COOLING_INFO_HASCOOLING = 1 , ARTEMIS_COOLING_INFO_CONTROLLABLE = 2 , ARTEMIS_COOLING_INFO_ONOFFCOOLINGCONTROL = 4 , ARTEMIS_COOLING_INFO_POWERLEVELCONTROL = 8 , ARTEMIS_COOLING_INFO_SETPOINTCONTROL = 16 , ARTEMIS_COOLING_INFO_WARMINGUP = 32 , ARTEMIS_COOLING_INFO_COOLINGON = 64 , ARTEMIS_COOLING_INFO_SETPOINTCONTROLON = 128 }
	Index into ArtemisCoolingInfo() Flags. More...

enum	ARTEMISEFWTYPE { ARTEMIS_EFW1 = 1 , ARTEMIS_EFW2 = 2 }
	Filter wheel type. More...

enum	CameraSpecificOptionsIDs { ID_GOPresetMode = 1 , ID_GOPresetLow = 2 , ID_GOPresetMed = 3 , ID_GOPresetHigh = 4 , ID_GOCustomGain = 5 , ID_GOCustomOffset = 6 , ID_EvenIllumination = 12 , ID_PadData = 13 , ID_ExposureSpeed = 14 , ID_BitSendMode = 15 , ID_FX3Version = 200 , ID_FPGAVersion = 201 }
	ID's for the camera specific options. More...

enum	HotPixelSensitivity { HPS_HIGH , HPS_MEDIUM , HPS_LOW }

Functions
artfn int	ArtemisAPIVersion ()
	Get API version. This may be the same as the DLL version. More...

artfn int	ArtemisDLLVersion ()
	Get DLL version. This may be the same as the API version. More...

artfn BOOL	ArtemisIsLocalConnection ()
	Gets whether the connection to the camera is local. More...

artfn void	ArtemisAllowDebugToConsole (bool value)
	Allows debug output to be output to standard error. More...

artfn void	ArtemisSetDebugCallback (void(callback)(const char message))
	Provide a pointer to a function, which will be invoked when debug output is produced. This can be used in combination with ArtemisAllowDebugToConsole. More...

artfn void	ArtemisSetDebugCallbackContext (void context, void(callback)(void context, const char message))
	Same as ArtemisSetDebugCallback(), but allows to pass an additional void pointer. This can be used to store a user-allocated data structure which will be passed to the callback. This pointer needs to be allocated and managed by the user. The context will never be freed by the API. More...

artfn void	ArtemisSetFirmwareDir (const char *firmwareDir)
	Internal function used during flashing. More...

artfn void	ArtemisSetAtikAir (const char *host, int port)
	Connect to an AtikAir instance. More...

artfn void	ArtemisShutdown ()
	Deallocates all internal DLL structures. The SDK functions may not be called after calling this function.

artfn int	ArtemisDeviceCount ()
	Returns the number of connected and recognised devices. The count does not include misconfigured devices (E.G. if drivers are missing). More...

artfn BOOL	ArtemisDeviceIsPresent (int iDevice)
	Duplicate of ArtemisDevicePresent(). More...

artfn BOOL	ArtemisDevicePresent (int iDevice)
	checks if the device at the index is connected. More...

artfn BOOL	ArtemisDeviceInUse (int iDevice)
	Checks if the device has already been connected to. More...

artfn BOOL	ArtemisDeviceName (int iDevice, char *pName)
	Retrieves the device's printable name. More...

artfn BOOL	ArtemisDeviceSerial (int iDevice, char *pSerial)
	Retrieves the device's serial number. More...

artfn BOOL	ArtemisDeviceIsCamera (int iDevice)
	Return whether the device at the specified index is a camera (and not E.G. a filter wheel device). More...

artfn BOOL	ArtemisDeviceHasFilterWheel (int iDevice)
	Return whether the device at the specified index has a filter wheel device. More...

artfn BOOL	ArtemisDeviceHasGuidePort (int iDevice)
	Return whether the device at the specified index has a guide port. More...

artfn ArtemisHandle	ArtemisConnect (int iDevice)

artfn BOOL	ArtemisIsConnected (ArtemisHandle handle)
	Returns whether the handle is currently connected to a camera. More...

artfn BOOL	ArtemisDisconnect (ArtemisHandle handle)
	Disconnects from the device with that handle and invalidates the handle. More...

artfn int	ArtemisRefreshDevicesCount ()
	Updates the available device count. More...

artfn int	ArtemisCameraSerial (ArtemisHandle handle, int flags, int serial)
	Retrieves the serial number of the connected device. More...

artfn int	ArtemisColourProperties (ArtemisHandle handle, ARTEMISCOLOURTYPE colourType, int normalOffsetX, int normalOffsetY, int previewOffsetX, int *previewOffsetY)
	Retrieves the colour properties of the the connected device. More...

artfn int	ArtemisProperties (ArtemisHandle handle, struct ARTEMISPROPERTIES *pProp)

artfn int	ArtemisCameraConnectionState (ArtemisHandle handle, ARTEMISCONNECTIONSTATE *state)
	Retrieves the camera connection state. More...

artfn int	ArtemisBin (ArtemisHandle handle, int x, int y)
	Sets the binning for the device. This will cause the resolution of the captured image to change accordingly with the requested bin values. More...

artfn int	ArtemisGetBin (ArtemisHandle handle, int x, int y)
	Gets the binning for the device. More...

artfn int	ArtemisGetMaxBin (ArtemisHandle handle, int x, int y)
	Retrieves the maximum binning supported by the device. More...

artfn int	ArtemisGetSubframe (ArtemisHandle handle, int x, int y, int w, int h)
	Retrieves the current subframing setting for the device. More...

artfn int	ArtemisSubframe (ArtemisHandle handle, int x, int y, int w, int h)
	Set the device's subframe position and size. This is equivalent to calling ArtemisSubframePos() followed by ArtemisSubframeSize(). More...

artfn int	ArtemisSubframePos (ArtemisHandle handle, int x, int y)
	Sets the device's subframe position. More...

artfn int	ArtemisSubframeSize (ArtemisHandle handle, int w, int h)
	Sets the device's subframe width and height. More...

artfn int	ArtemisSetSubSample (ArtemisHandle handle, bool bSub)
	Set whether subsampling mode is enabled on the device. More...

artfn BOOL	ArtemisContinuousExposingModeSupported (ArtemisHandle handle)
	Retrieves whether continuous exposing is supported by the device. More...

artfn BOOL	ArtemisGetContinuousExposingMode (ArtemisHandle handle)
	Retrieves whether continuous exposing is enabled for the device. More...

artfn int	ArtemisSetContinuousExposingMode (ArtemisHandle handle, bool bEnable)
	Set whether continuous exposing mode is enabled. This only has an effect on supported devices. More...

artfn BOOL	ArtemisGetDarkMode (ArtemisHandle handle)
	Retrieves whether dark mode is enabled for the device. More...

artfn int	ArtemisSetDarkMode (ArtemisHandle handle, bool bEnable)
	Sets whether dark mode is enabled for the device. More...

artfn int	ArtemisSetPreview (ArtemisHandle handle, bool bPrev)
	Sets whether preview mode is enabled for the device. If preview mode is enabled, the sensor is not cleared between exposures. Using preview mode, there might be more noise/glow in the resulting image. More...

artfn int	ArtemisAutoAdjustBlackLevel (ArtemisHandle handle, bool bEnable)
	Sets whether black auto-adjustment is enabled. More...

artfn int	ArtemisPrechargeMode (ArtemisHandle handle, int mode)
	Sets the precharge mode of the camera. Precharge applies an in-camera offset, mainly for astronomy use. More...

artfn int	ArtemisEightBitMode (ArtemisHandle handle, bool eightbit)
	Sets whether 8-bit mode is enabled on the device. This affects the size of the returned image buffer, which by default is 16 bits per pixel. More...

artfn int	ArtemisGetEightBitMode (ArtemisHandle handle, bool *eightbit)
	Retrieves whether 8-bit mode is enabled on the device. More...

artfn int	ArtemisStartOverlappedExposure (ArtemisHandle handle)
	Begin an overlapped exposure. More...

artfn BOOL	ArtemisOverlappedExposureValid (ArtemisHandle handle)
	Returns whether the overlapped exposure is still valid. More...

artfn int	ArtemisSetOverlappedExposureTime (ArtemisHandle handle, float fSeconds)
	Set the overlapped exposure time. More...

artfn int	ArtemisTriggeredExposure (ArtemisHandle handle, bool bAwaitTrigger)
	Sets whether the device will await a triggered exposure. More...

artfn int	ArtemisGetProcessing (ArtemisHandle handle)
	Return which post processing flags are enabled for the device. More...

artfn int	ArtemisSetProcessing (ArtemisHandle handle, int options)
	Sets which post processing effects are enabled for the device. More...

artfn int	ArtemisStartExposure (ArtemisHandle handle, float seconds)
	Begin an exposure for the device, specifying a duration as floating point seconds. More...

artfn int	ArtemisStartExposureMS (ArtemisHandle handle, int ms)
	Begin an exposure for the device, specifying a duration as milliseconds. More...

artfn int	ArtemisAbortExposure (ArtemisHandle handle)
	Stop the current exposure for the device. This is analogous to ArtemisStopExposure(). More...

artfn int	ArtemisStopExposure (ArtemisHandle handle)
	Stop the current exposure for the device. This is analogous to ArtemisAbortExposure(). More...

artfn BOOL	ArtemisImageReady (ArtemisHandle handle)
	Returns whether the image has been fully downloaded and is ready to access. This method can be polled until it returns TRUE, after which ArtemisGetImageData() and ArtemisImageBuffer() can be called to get the results of the exposure. It is recommended to add a delay in between polling (E.G. 10 milliseconds). More...

artfn int	ArtemisCameraState (ArtemisHandle handle)
	Returns the device's state as an ARTEMISCAMERASTATE enumeration. More...

artfn float	ArtemisExposureTimeRemaining (ArtemisHandle handle)
	Returns how much time is left in the exposure as a floating point number. Note this does not include the download time. More...

artfn int	ArtemisDownloadPercent (ArtemisHandle handle)
	Returns the download progress in percent. More...

artfn int	ArtemisGetImageData (ArtemisHandle handle, int x, int y, int w, int h, int binx, int biny)
	Provides information about the latest acquired image. More...

artfn void *	ArtemisImageBuffer (ArtemisHandle handle)
	Returns a pointer to the internal image buffer which contains the latest captured image. The buffer size can be calculated by width * height * pixel depth. More...

artfn float	ArtemisLastExposureDuration (ArtemisHandle handle)
	Returns the duration of the last exposure as floating point number of seconds. More...

artfn char *	ArtemisLastStartTime (ArtemisHandle handle)
	Returns a pointer to the formatted last exposure start time. The buffer is internal to the SDK and is overwritten every time this function is called. Does not include milliseconds. More...

artfn int	ArtemisLastStartTimeMilliseconds (ArtemisHandle handle)
	Returns the last exposure start time millisecond component. More...

artfn int	ArtemisClearVReg (ArtemisHandle handle)
	This API is for internal use. More...

artfn BOOL	ArtemisHasFastMode (ArtemisHandle handle)
	Gets whether the device supports fast mode. More...

artfn BOOL	ArtemisStartFastExposure (ArtemisHandle handle, int ms)
	Begins a fast mode exposure. More...

artfn BOOL	ArtemisSetFastCallback (ArtemisHandle handle, void(callback)(ArtemisHandle handle, int x, int y, int w, int h, int binx, int biny, void imageBuffer))
	Set the callback that will be invoked when a fast mode exposure is completed. More...

artfn int	ArtemisAmplifier (ArtemisHandle handle, bool bOn)
	Enable/disable the device's amplifier. This function is equivalent to ArtemisSetAmplifierSwitched(). More...

artfn BOOL	ArtemisGetAmplifierSwitched (ArtemisHandle handle)
	Returns whether the amplifier is enabled. More...

artfn int	ArtemisSetAmplifierSwitched (ArtemisHandle handle, bool bSwitched)
	Enable/disable the device's amplifier. This function is equivalent to ArtemisAmplifier(). More...

artfn bool	ArtemisHasCameraSpecificOption (ArtemisHandle handle, unsigned short id)
	Returns whether the specified option is available. More...

artfn int	ArtemisCameraSpecificOptionGetData (ArtemisHandle handle, unsigned short id, unsigned char data, int dataLength, int actualLength)
	Used to get the specified option's current value. Please check that the current camera has this option using ArtemisHasCameraSpecificOption() More...

artfn int	ArtemisCameraSpecificOptionSetData (ArtemisHandle handle, unsigned short id, unsigned char *data, int dataLength)
	Used to set the specified option's value. Please check that the current camera has this option using ArtemisHasCameraSpecificOption() More...

artfn int	ArtemisSetColumnRepairColumns (ArtemisHandle handle, int nColumn, unsigned short *columns)
	Set the columns on which column repair post processing is performed. More...

artfn int	ArtemisGetColumnRepairColumns (ArtemisHandle handle, int nColumn, unsigned short columns)
	Get the columns on which column repair post processing is performed. More...

artfn int	ArtemisClearColumnRepairColumns (ArtemisHandle handle)
	Remove all column repair processing set previously. More...

artfn int	ArtemisSetColumnRepairFixColumns (ArtemisHandle handle, bool value)
	Sets whether column repair is enabled. More...

artfn int	ArtemisGetColumnRepairFixColumns (ArtemisHandle handle, bool *value)
	Retrieves whether column repair is enabled or not. More...

artfn int	ArtemisGetColumnRepairCanFixColumns (ArtemisHandle handle, bool *value)
	Retrieves whether column repair can be enabled. More...

artfn int	ArtemisCanInteractWithEEPROM (ArtemisHandle handle, bool *canInteract)
	Retrieves whether the EEPROM can be interacted with. This API is for internal use. More...

artfn int	ArtemisWriteToEEPROM (ArtemisHandle handle, char password, int address, int length, const unsigned char data)
	Writes a value to the EEPROM. This API is for internal use. More...

artfn int	ArtemisReadFromEEPROM (ArtemisHandle handle, char password, int address, int length, unsigned char data)
	Reads a value from the EEPROM. This API is for internal use. More...

artfn int	ArtemisFilterWheelInfo (ArtemisHandle handle, int numFilters, int moving, int currentPos, int targetPos)
	Retrieve the state of the filter wheel. More...

artfn int	ArtemisFilterWheelMove (ArtemisHandle handle, int targetPos)
	Move the filter wheel to the desired location. More...

artfn BOOL	ArtemisEFWIsPresent (int i)
	Checks whether a filter wheel is present at the index. More...

artfn int	ArtemisEFWGetDeviceDetails (int i, ARTEMISEFWTYPE type, char serialNumber)
	Get information on the filter wheel device at the specified index. This is the same as ArtemisEFWGetDetails(), but without connecting first. More...

artfn ArtemisHandle	ArtemisEFWConnect (int i)
	Connect to a filter wheel device at the specified index. More...

artfn bool	ArtemisEFWIsConnected (ArtemisHandle handle)
	Retrieves whether the handle for the filter wheel is valid. More...

artfn int	ArtemisEFWDisconnect (ArtemisHandle handle)
	Disconnect from the filter wheel handle. More...

artfn int	ArtemisEFWGetDetails (ArtemisHandle handle, ARTEMISEFWTYPE type, char serialNumber)
	Get information on the connected filter wheel device. This is the same as ArtemisEFWGetDeviceDetails(), after connecting. More...

artfn int	ArtemisEFWNmrPosition (ArtemisHandle handle, int *nPosition)
	Gets the number of filters inside the filter wheel. More...

artfn int	ArtemisEFWSetPosition (ArtemisHandle handle, int iPosition)
	Sets the device's filter wheel position. More...

artfn int	ArtemisEFWGetPosition (ArtemisHandle handle, int iPosition, bool isMoving)
	Gets the device's filter wheel position. More...

artfn bool	ArtemisCanUploadFirmware (ArtemisHandle handle)
	Returns whether firmware can be uploaded to the device. This API is for internal use. More...

artfn int	ArtemisUploadFirmware (ArtemisHandle handle, char fileName, char password)
	Upload a new firmware on the device. This API is for internal use. More...

artfn int	ArtemisGetGain (ArtemisHandle handle, bool isPreview, int gain, int offset)
	Get the currently set gain and offset for the device. Note that Horizon/ACIS cameras need to use ArtemisCameraSpecificOptionGetData() to get the gain. More...

artfn int	ArtemisSetGain (ArtemisHandle handle, bool isPreview, int gain, int offset)
	Set the gain and offset for the device Note that Horizon/ACIS cameras need to use ArtemisCameraSpecificOptionSetData() to set the gain. More...

artfn int	ArtemisGetGpioInformation (ArtemisHandle handle, int lineCount, int lineValues)

artfn int	ArtemisSetGpioDirection (ArtemisHandle handle, int directionMask)

artfn int	ArtemisSetGpioValues (ArtemisHandle handle, int lineValues)

artfn int	ArtemisGuide (ArtemisHandle handle, int axis)

artfn int	ArtemisGuidePort (ArtemisHandle handle, int nibble)

artfn int	ArtemisPulseGuide (ArtemisHandle handle, int axis, int milli)

artfn int	ArtemisStopGuiding (ArtemisHandle handle)

artfn int	ArtemisStopGuidingBeforeDownload (ArtemisHandle handle, bool bEnable)

artfn int	ArtemisAutoHotPixelRemoval (ArtemisHandle handle, bool on)
	A software based hot pixel remover with some pre defined parameters. darkFrame = false, checkForAdjacentHotPixels = false, hps = HPS_MEDIUM. More...

artfn int	ArtemisAdvancedHotPixelRemoval (ArtemisHandle handle, bool on, bool darkFrame, bool checkForAdjacentHotPixels, HotPixelSensitivity hps)
	A software based hot pixel remover with several parameters. If dakFrame is true this function will block for 30 seconds. More...

artfn int	ArtemisGetLensAperture (ArtemisHandle handle, int *aperture)
	Gets the current lens aperture value. More...

artfn int	ArtemisGetLensFocus (ArtemisHandle handle, int *focus)
	Gets the current lens focus value. More...

artfn int	ArtemisGetLensLimits (ArtemisHandle handle, int apertureMin, int apertureMax, int focusMin, int focusMax)
	Returns the lens numerical limits for the device. More...

artfn int	ArtemisInitializeLens (ArtemisHandle handle)
	Initialise lens controls. If not called, lens control methods will return ARTEMIS_NOT_INITIALIZED. More...

artfn int	ArtemisSetLensAperture (ArtemisHandle handle, int aperture)
	Sets the lens aperture. More...

artfn int	ArtemisSetLensFocus (ArtemisHandle handle, int focus)
	Sets the lens focus. More...

artfn int	ArtemisCanControlShutter (ArtemisHandle handle, bool *canControl)
	Checks whether the shutter can be opened and closed on the device. More...

artfn int	ArtemisOpenShutter (ArtemisHandle handle)
	Opens the shutter on the device. Please call ArtemisCanControlShutter() to see if the shutter can be controlled. More...

artfn int	ArtemisCloseShutter (ArtemisHandle handle)
	Closes the shutter on the device. Please call ArtemisCanControlShutter() to see if the shutter can be controlled. More...

artfn int	ArtemisCanSetShutterSpeed (ArtemisHandle handle, bool *canSetShutterSpeed)
	Checks whether the shutter speed can be set on the device. More...

artfn int	ArtemisGetShutterSpeed (ArtemisHandle handle, int *speed)
	Gets the shutter speed. More...

artfn int	ArtemisSetShutterSpeed (ArtemisHandle handle, int speed)
	Sets the shutter speed. More...

artfn int	ArtemisTemperatureSensorInfo (ArtemisHandle handle, int sensor, int *temperature)
	Gets temperature of the device for the specific sensor index, in hundreds of degrees centigrade. If "sensor" is set to 0, this will be set to the number of temperature sensors on the device. More...

artfn int	ArtemisSetCooling (ArtemisHandle handle, int setpoint)
	Sets the cooling target temperature of the device. This will override ArtemisSetCoolingPower(). More...

artfn int	ArtemisSetCoolingPower (ArtemisHandle handle, int power)
	Sets the cooling power of the cooler directly. This will override ArtemisSetCooling(). More...

artfn int	ArtemisCoolingInfo (ArtemisHandle handle, int flags, int level, int minlvl, int maxlvl, int *setpoint)
	Retrieves information about the cooling settings for the device. More...

artfn int	ArtemisCoolerWarmUp (ArtemisHandle handle)
	Disables active cooling for the device. On some devices, this will perform a slow ramp down of the cooler, to avoid thermal shock. More...

artfn int	ArtemisGetWindowHeaterPower (ArtemisHandle handle, int *windowHeaterPower)
	Gets the window heater power. More...

artfn int	ArtemisSetWindowHeaterPower (ArtemisHandle handle, int windowHeaterPower)
	Sets the window heater power. More...

artfn bool	ArtemisLoadDLL (const char *fileName)
	Dynamically loads the Atik implementation DLL. This method is only needed if the DLL is linked dynamically. This method is part of the DLL example code. More...

artfn void	ArtemisUnLoadDLL ()
	Unloads the Atik DLL and frees the internal DLL handle. This method is only needed if the DLL is linked dynamically. This method is part of the DLL example code. More...

Variables
static HINSTANCE	hArtemisDLL = NULL
	DLL handle set by ArtemisLoadDLL(). This is irrelevant if you are linking at compile time.

Detailed Description

Atik SDK C interface header.

Typedef Documentation

◆ ArtemisHandle

typedef void* ArtemisHandle

Atik SDK handle type

See also: ArtemisConnect(), ArtemisEFWConnect()

Enumeration Type Documentation

◆ ARTEMISCAMERASTATE

enum ARTEMISCAMERASTATE

See also: ArtemisCameraState()

◆ ARTEMISCOLOURTYPE

enum ARTEMISCOLOURTYPE

Camera colour properties.

Enumerator
ARTEMIS_COLOUR_UNKNOWN	Either the device is not a camera or the colour cannot be determined.
ARTEMIS_COLOUR_NONE	Device sensor is monochrome.
ARTEMIS_COLOUR_RGGB	Device sensor is colour (RGGB)

◆ ARTEMISCOOLINGINFO

enum ARTEMISCOOLINGINFO

Index into ArtemisCoolingInfo() Flags.

See also: ArtemisCoolingInfo()

Enumerator
ARTEMIS_COOLING_INFO_HASCOOLING	Camera can be cooled. 0= No cooling ability 1= Has cooling.
ARTEMIS_COOLING_INFO_CONTROLLABLE	Cooling is always on or can be controlled. 0= Always on 1= Controllable.
ARTEMIS_COOLING_INFO_ONOFFCOOLINGCONTROL	Cooling can be switched On/Off. 0= On/Off control not available 1= On/Off control available.
ARTEMIS_COOLING_INFO_POWERLEVELCONTROL	Cooling can be set via ArtemisSetCoolingPower()
ARTEMIS_COOLING_INFO_SETPOINTCONTROL	Cooling can be set via ArtemisSetCooling()
ARTEMIS_COOLING_INFO_WARMINGUP	Currently warming up. 0= Normal control 1= Warming Up.
ARTEMIS_COOLING_INFO_COOLINGON	Currently cooling. 0= Cooling off 1= Cooling on.
ARTEMIS_COOLING_INFO_SETPOINTCONTROLON	Currently under setpoint control 0= No set point control 1= Set point control.

◆ ARTEMISEFWTYPE

enum ARTEMISEFWTYPE

Filter wheel type.

Note: An EFW3 will show as EFW2 as they use the same firmware

See also: ArtemisEFWGetDeviceDetails()

◆ ARTEMISERROR

enum ARTEMISERROR

Main error enum for methods with "int" as return type.

Enumerator
ARTEMIS_OK	Operation successful.
ARTEMIS_INVALID_PARAMETER	The camera handle passed is not a valid handle. See also ArtemisConnect()
ARTEMIS_NOT_CONNECTED	Camera is not connected.
ARTEMIS_NOT_IMPLEMENTED	Not impl.
ARTEMIS_NO_RESPONSE	No response.
ARTEMIS_INVALID_FUNCTION	Invalid function.
ARTEMIS_NOT_INITIALIZED	Camera Not init.
ARTEMIS_OPERATION_FAILED	Failed.

◆ ARTEMISPRECHARGEMODE

enum ARTEMISPRECHARGEMODE

Enumerator
PRECHARGE_NONE	Precharge ignored.
PRECHARGE_ICPS	In-camera precharge subtraction.
PRECHARGE_FULL	Precharge sent with image data.

◆ ARTEMISPROCESSING

enum ARTEMISPROCESSING

Flags for ArtemisGet/SetProcessing

See also: ArtemisGetProcessing(), ArtemisSetProcessing()

Enumerator
ARTEMIS_PROCESS_LINEARISE	compensate for JFET nonlinearity
ARTEMIS_PROCESS_VBE	adjust for 'Venetian Blind effect'

◆ ARTEMISPROPERTIESCAMERAFLAGS

enum ARTEMISPROPERTIESCAMERAFLAGS

Index into the camera flags of ARTEMISPROPERTIES

See also: ARTEMISPROPERTIES

Enumerator
ARTEMIS_PROPERTIES_CAMERAFLAGS_FIFO	Camera has readout FIFO fitted.
ARTEMIS_PROPERTIES_CAMERAFLAGS_EXT_TRIGGER	Camera has external trigger capabilities.
ARTEMIS_PROPERTIES_CAMERAFLAGS_PREVIEW	Camera can return preview data.
ARTEMIS_PROPERTIES_CAMERAFLAGS_SUBSAMPLE	Camera can return subsampled data.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_SHUTTER	Camera has a mechanical shutter.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_GUIDE_PORT	Camera has a guide port.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_GPIO	Camera has GPIO capability.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_WINDOW_HEATER	Camera has a window heater.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_EIGHT_BIT_MODE	Camera can download 8-bit images.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_OVERLAP_MODE	Camera can overlap.
ARTEMIS_PROPERTIES_CAMERAFLAGS_HAS_FILTERWHEEL	Camera has internal filterwheel.
ARTEMIS_PROPERTIES_CAMERAFLAGS_DUMMY	Enum padding to 4 bytes. Not used.

◆ ARTEMISPROPERTIESCCDFLAGS

enum ARTEMISPROPERTIESCCDFLAGS

Index into the ccdflags value of ARTEMISPROPERTIES.

See also: ARTEMISPROPERTIES

Enumerator
ARTEMIS_PROPERTIES_CCDFLAGS_INTERLACED	CCD is interlaced type.
ARTEMIS_PROPERTIES_CCDFLAGS_DUMMY	Enum padding to 4 bytes. Not used.

◆ CameraSpecificOptionsIDs

enum CameraSpecificOptionsIDs

ID's for the camera specific options.

See also: ArtemisHasCameraSpecificOption()

Function Documentation

◆ ArtemisAbortExposure()

artfn int ArtemisAbortExposure ( ArtemisHandle handle )

Stop the current exposure for the device. This is analogous to ArtemisStopExposure().

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR, ArtemisStartExposure(), ArtemisStartExposureMS(), ArtemisStopExposure()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisAdvancedHotPixelRemoval()

artfn int ArtemisAdvancedHotPixelRemoval	(	ArtemisHandle	handle,
		bool	on,
		bool	darkFrame,
		bool	checkForAdjacentHotPixels,
		HotPixelSensitivity	hps
	)

A software based hot pixel remover with several parameters. If dakFrame is true this function will block for 30 seconds.

Parameters

handle	the connected Atik device handle.
on	turns the hot pixel removal off/on
darkFrame	If true, a 30 second dark frame will be taken. This will create a hot pixel array internally that will be used after exposure to remove hot pixels. This array will need to be regenerated on any dimension or binning change otherwise the hot pixel removal will not be applied. If this parameter is used hot pixels will not be determined during exposure only those listed in the array will be fixed. If false the internal hot pixel array will be regenarated for each exposure
checkForAdjacentHotPixels	If true surrounding hot pixels will not be used to determine the value of the current hot pixel. This option trades time against better quality results.
hps	This determines what is seen as a hot pixel. HPS_HIGH will see the most hot pixels.

◆ ArtemisAllowDebugToConsole()

artfn void ArtemisAllowDebugToConsole ( bool value )

Allows debug output to be output to standard error.

Parameters

value Whether to enable the output.

See also: ArtemisAllowDebugCallback(), ArtemisAllowDebugCallbackContext()

◆ ArtemisAmplifier()

artfn int ArtemisAmplifier	(	ArtemisHandle	handle,
		bool	bOn
	)

Enable/disable the device's amplifier. This function is equivalent to ArtemisSetAmplifierSwitched().

Parameters

handle	the connected Atik device handle.
bOn	whether to enable or disable the built in amplifier.

See also: ARTEMISERROR, ArtemisSetAmplifierSwitched()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisAPIVersion()

artfn int ArtemisAPIVersion ( )

Get API version. This may be the same as the DLL version.

Returns: API version as an integer, such as: 20200904

◆ ArtemisAutoAdjustBlackLevel()

artfn int ArtemisAutoAdjustBlackLevel	(	ArtemisHandle	handle,
		bool	bEnable
	)

Sets whether black auto-adjustment is enabled.

Parameters

handle	the connected Atik device handle.
bEnable	whether black levels will be auto-adjusted.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisAutoHotPixelRemoval()

artfn int ArtemisAutoHotPixelRemoval	(	ArtemisHandle	handle,
		bool	on
	)

A software based hot pixel remover with some pre defined parameters. darkFrame = false, checkForAdjacentHotPixels = false, hps = HPS_MEDIUM.

See also: ArtemisAdvancedHotPixelRemoval()

Parameters

handle	the connected Atik device handle.
on	turns the hot pixel removal off/on

◆ ArtemisBin()

artfn int ArtemisBin	(	ArtemisHandle	handle,
		int	x,
		int	y
	)

Sets the binning for the device. This will cause the resolution of the captured image to change accordingly with the requested bin values.

Parameters

handle	the connected Atik device handle.
x	the X binning value.
y	the Y binning value.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCameraConnectionState()

artfn int ArtemisCameraConnectionState	(	ArtemisHandle	handle,
		ARTEMISCONNECTIONSTATE *	state
	)

Retrieves the camera connection state.

Parameters

handle	the connected Atik device handle.
state	if successful, a pointer to a user provided ARTEMISCONNECTIONSTATE instance.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCameraSerial()

artfn int ArtemisCameraSerial	(	ArtemisHandle	handle,
		int *	flags,
		int *	serial
	)

Retrieves the serial number of the connected device.

Parameters

handle	the connected device handle.
flags	a pointer to an integer which will be set to internal device flags.
serial	a pointer to an integer which will be set to the serial number of the connected Atik device.

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure.

◆ ArtemisCameraSpecificOptionGetData()

artfn int ArtemisCameraSpecificOptionGetData	(	ArtemisHandle	handle,
		unsigned short	id,
		unsigned char *	data,
		int	dataLength,
		int *	actualLength
	)

Used to get the specified option's current value. Please check that the current camera has this option using ArtemisHasCameraSpecificOption()

Parameters

handle	the connected Atik device handle.
id
data
dataLength
actualLength

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_PARAM if the opton is not available or ARTEMISERROR on failure

◆ ArtemisCameraSpecificOptionSetData()

artfn int ArtemisCameraSpecificOptionSetData	(	ArtemisHandle	handle,
		unsigned short	id,
		unsigned char *	data,
		int	dataLength
	)

Used to set the specified option's value. Please check that the current camera has this option using ArtemisHasCameraSpecificOption()

Parameters

handle	the connected Atik device handle.
id
data
dataLength

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_PARAM if the opton is not available or ARTEMISERROR on failure

◆ ArtemisCameraState()

artfn int ArtemisCameraState ( ArtemisHandle handle )

Returns the device's state as an ARTEMISCAMERASTATE enumeration.

Parameters

handle the connected device handle.

See also: ARTEMISERROR, ARTEMISCAMERASTATE

Returns: ARTEMISCAMERASTATE enumeration value.

◆ ArtemisCanControlShutter()

artfn int ArtemisCanControlShutter	(	ArtemisHandle	handle,
		bool *	canControl
	)

Checks whether the shutter can be opened and closed on the device.

Parameters

handle	the connected Atik device handle.
canControl	a pointer to a boolean which will be set to whether the shutter can be opened and closed.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCanInteractWithEEPROM()

artfn int ArtemisCanInteractWithEEPROM	(	ArtemisHandle	handle,
		bool *	canInteract
	)

Retrieves whether the EEPROM can be interacted with. This API is for internal use.

Parameters

handle	the connected Atik device handle.
canInteract

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCanSetShutterSpeed()

artfn int ArtemisCanSetShutterSpeed	(	ArtemisHandle	handle,
		bool *	canSetShutterSpeed
	)

Checks whether the shutter speed can be set on the device.

Parameters

handle	the connected Atik device handle.
canSetShutterSpeed	a pointer to a boolean which will be set to whether the shutter speed can be set.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCanUploadFirmware()

artfn bool ArtemisCanUploadFirmware ( ArtemisHandle handle )

Returns whether firmware can be uploaded to the device. This API is for internal use.

Parameters

handle the connected Atik device handle.

Returns: true if it can upload, false if not.

◆ ArtemisClearColumnRepairColumns()

artfn int ArtemisClearColumnRepairColumns ( ArtemisHandle handle )

Remove all column repair processing set previously.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisClearVReg()

artfn int ArtemisClearVReg ( ArtemisHandle handle )

This API is for internal use.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCloseShutter()

artfn int ArtemisCloseShutter ( ArtemisHandle handle )

Closes the shutter on the device. Please call ArtemisCanControlShutter() to see if the shutter can be controlled.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR, ArtemisCanControlShutter()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisColourProperties()

artfn int ArtemisColourProperties	(	ArtemisHandle	handle,
		ARTEMISCOLOURTYPE *	colourType,
		int *	normalOffsetX,
		int *	normalOffsetY,
		int *	previewOffsetX,
		int *	previewOffsetY
	)

Retrieves the colour properties of the the connected device.

Parameters

handle	the connected device handle.
colourType	a pointer to a user provided ARTEMISCOLOURTYPE enum which will be set to an ARTEMISCOLOURTYPE value.
normalOffsetX	a pointer to an integer which will be set to the normal offset over the X axis.
normalOffsetY	a pointer to an integer which will be set to the normal offset over the Y axis.
previewOffsetX	a pointer to an integer which will be set to the preview offset over the X axis.
previewOffsetY	a pointer to an integer which will be set to the preview offset over the Y axis.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisConnect()

artfn ArtemisHandle ArtemisConnect ( int iDevice )

Connect to an Atik device by index and obtain an ArtemisHandle to it for further use. Use ArtemisDeviceCount to discover how many devices are available for connection.

Parameters

iDevice Device index. Use 0 if using a single camera.

Returns: Non-null ArtemisHandle if successful, null on failure.

See also: ArtemisDeviceCount()

◆ ArtemisContinuousExposingModeSupported()

artfn BOOL ArtemisContinuousExposingModeSupported ( ArtemisHandle handle )

Retrieves whether continuous exposing is supported by the device.

Parameters

handle the connected Atik device handle.

Returns: TRUE if supported, FALSE if not.

◆ ArtemisCoolerWarmUp()

artfn int ArtemisCoolerWarmUp ( ArtemisHandle handle )

Disables active cooling for the device. On some devices, this will perform a slow ramp down of the cooler, to avoid thermal shock.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisCoolingInfo()

artfn int ArtemisCoolingInfo	(	ArtemisHandle	handle,
		int *	flags,
		int *	level,
		int *	minlvl,
		int *	maxlvl,
		int *	setpoint
	)

Retrieves information about the cooling settings for the device.

Parameters

handle	the connected Atik device handle.
flags	internal flags representing the cooling state.
level	the power level of the cooler, usually from 0 to 255.
minlvl	displays the minimum cooling power level
maxlvl	displays the maximum cooling power level
setpoint	the target setpoint temperature for the camera in degrees celsius.

See also: ARTEMISERROR, ArtemisSetCoolingPower()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisDeviceCount()

artfn int ArtemisDeviceCount ( )

Returns the number of connected and recognised devices. The count does not include misconfigured devices (E.G. if drivers are missing).

Returns: The number of connected and recognised devices.

◆ ArtemisDeviceHasFilterWheel()

artfn BOOL ArtemisDeviceHasFilterWheel ( int iDevice )

Return whether the device at the specified index has a filter wheel device.

Parameters

iDevice the device index.

Returns: TRUE if the device has a filter wheel device, FALSE otherwise

◆ ArtemisDeviceHasGuidePort()

artfn BOOL ArtemisDeviceHasGuidePort ( int iDevice )

Return whether the device at the specified index has a guide port.

Parameters

iDevice the device index.

Returns: TRUE if the device has a guide port, FALSE otherwise

◆ ArtemisDeviceInUse()

artfn BOOL ArtemisDeviceInUse ( int iDevice )

Checks if the device has already been connected to.

Parameters

iDevice the device index.

Returns: TRUE if the device is has a handle acquired to it, FALSE otherwise

◆ ArtemisDeviceIsCamera()

artfn BOOL ArtemisDeviceIsCamera ( int iDevice )

Return whether the device at the specified index is a camera (and not E.G. a filter wheel device).

Parameters

iDevice the device index.

Returns: TRUE if the device is a camera, FALSE otherwise

◆ ArtemisDeviceIsPresent()

artfn BOOL ArtemisDeviceIsPresent ( int iDevice )

Duplicate of ArtemisDevicePresent().

Parameters

iDevice the device index.

Returns: TRUE if the device is present, FALSE otherwise

See also: ArtemisDevicePresent()

◆ ArtemisDeviceName()

artfn BOOL ArtemisDeviceName	(	int	iDevice,
		char *	pName
	)

Retrieves the device's printable name.

Parameters

iDevice	the device index.
pName	a pointer to a user-allocated char array of length 100.

Returns: TRUE if the name was set successfully, FALSE if not.

◆ ArtemisDevicePresent()

artfn BOOL ArtemisDevicePresent ( int iDevice )

checks if the device at the index is connected.

Parameters

iDevice the device index.

Returns: TRUE if the device is present, FALSE otherwise

◆ ArtemisDeviceSerial()

artfn BOOL ArtemisDeviceSerial	(	int	iDevice,
		char *	pSerial
	)

Retrieves the device's serial number.

Parameters

iDevice	the device index.
pSerial	a pointer to a user-allocated char array of length 100.

Returns: TRUE if the name was set successfully, FALSE if not.

◆ ArtemisDisconnect()

artfn BOOL ArtemisDisconnect ( ArtemisHandle handle )

Disconnects from the device with that handle and invalidates the handle.

Parameters

handle The device handle

Returns: TRUE if the handle disconnection was successful, FALSE otherwise

See also: ArtemisConnect()

◆ ArtemisDLLVersion()

artfn int ArtemisDLLVersion ( )

Get DLL version. This may be the same as the API version.

Returns: API version as an integer, such as: 20200904

◆ ArtemisDownloadPercent()

artfn int ArtemisDownloadPercent ( ArtemisHandle handle )

Returns the download progress in percent.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: the download progress in percent (0-100).

◆ ArtemisEFWConnect()

artfn ArtemisHandle ArtemisEFWConnect ( int i )

Connect to a filter wheel device at the specified index.

Parameters

i	The index of the filter wheel device to connect to.

Returns: a valid ArtemisHandle on success, NULL on failure.

◆ ArtemisEFWDisconnect()

artfn int ArtemisEFWDisconnect ( ArtemisHandle handle )

Disconnect from the filter wheel handle.

Parameters

handle the connected Atik device handle.

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisEFWGetDetails()

artfn int ArtemisEFWGetDetails	(	ArtemisHandle	handle,
		ARTEMISEFWTYPE *	type,
		char *	serialNumber
	)

Get information on the connected filter wheel device. This is the same as ArtemisEFWGetDeviceDetails(), after connecting.

Parameters

handle	the connected Atik device handle.
type	a pointer to an ARTEMISEFWTYPE enumeration, which will be set to the type of the filter wheel device.
serialNumber	a pointer to a char array of length 100, which will be set to the serial number of the filter wheel.

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisEFWGetDeviceDetails()

artfn int ArtemisEFWGetDeviceDetails	(	int	i,
		ARTEMISEFWTYPE *	type,
		char *	serialNumber
	)

Get information on the filter wheel device at the specified index. This is the same as ArtemisEFWGetDetails(), but without connecting first.

Parameters

i	the index to get details for.
type	a pointer to an ARTEMISEFWTYPE enumeration, which will be set to the type of the filter wheel device.
serialNumber	a pointer to a char array of length 100, which will be set to the serial number of the filter wheel.

See also: ARTEMISERROR, ARTEMISEFWTYPE, ArtemisEFWGetDetails()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisEFWGetPosition()

artfn int ArtemisEFWGetPosition	(	ArtemisHandle	handle,
		int *	iPosition,
		bool *	isMoving
	)

Gets the device's filter wheel position.

Parameters

handle	the connected Atik device handle.
iPosition	pointer to an integer which will be set to the filter wheel's current position.
isMoving	pointer to a boolean which will be set to whether the filter wheel is currently moving.

Returns

◆ ArtemisEFWIsConnected()

artfn bool ArtemisEFWIsConnected ( ArtemisHandle handle )

Retrieves whether the handle for the filter wheel is valid.

Parameters

handle the filter wheel handle.

See also: ARTEMISERROR

Returns: true if connected, false if not.

◆ ArtemisEFWIsPresent()

artfn BOOL ArtemisEFWIsPresent ( int i )

Checks whether a filter wheel is present at the index.

Parameters

i	the index to check.

Returns: TRUE if present, FALSE if not.

◆ ArtemisEFWNmrPosition()

artfn int ArtemisEFWNmrPosition	(	ArtemisHandle	handle,
		int *	nPosition
	)

Gets the number of filters inside the filter wheel.

Parameters

handle	the connected Atik device handle.
nPosition	a pointer to an integer which will be set to the current filter wheel position.

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisEFWSetPosition()

artfn int ArtemisEFWSetPosition	(	ArtemisHandle	handle,
		int	iPosition
	)

Sets the device's filter wheel position.

Parameters

handle	the connected Atik device handle.
iPosition	the desired position

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisEightBitMode()

artfn int ArtemisEightBitMode	(	ArtemisHandle	handle,
		bool	eightbit
	)

Sets whether 8-bit mode is enabled on the device. This affects the size of the returned image buffer, which by default is 16 bits per pixel.

Parameters

handle	the connected Atik device handle.
eightbit	whether to enable 8-bit mode.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisExposureTimeRemaining()

artfn float ArtemisExposureTimeRemaining ( ArtemisHandle handle )

Returns how much time is left in the exposure as a floating point number. Note this does not include the download time.

Parameters

handle the connected device handle.

See also: ArtemisImageReady(), ArtemisStartExposure()

Returns: the number of seconds remaining in the exposure as a floating point number.

◆ ArtemisFilterWheelInfo()

artfn int ArtemisFilterWheelInfo	(	ArtemisHandle	handle,
		int *	numFilters,
		int *	moving,
		int *	currentPos,
		int *	targetPos
	)

Retrieve the state of the filter wheel.

Parameters

handle	the connected Atik device handle.
numFilters	pointer to an integer which will be set to the number of filters in the filter wheel.
moving	pointer to an integer which will be set to 1 if the filter wheel is moving, 0 otherwise.
currentPos	pointer to an integer which will be set to the current position.
targetPos	pointer to an integer which will be set to the target position.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisFilterWheelMove()

artfn int ArtemisFilterWheelMove	(	ArtemisHandle	handle,
		int	targetPos
	)

Move the filter wheel to the desired location.

Parameters

handle	the connected Atik device handle.
targetPos	the target filter wheel position.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetAmplifierSwitched()

artfn BOOL ArtemisGetAmplifierSwitched ( ArtemisHandle handle )

Returns whether the amplifier is enabled.

Parameters

handle the connected Atik device handle.

Returns: TRUE if the amplifier is enabled, FALSE otherwise.

◆ ArtemisGetBin()

artfn int ArtemisGetBin	(	ArtemisHandle	handle,
		int *	x,
		int *	y
	)

Gets the binning for the device.

Parameters

handle	the connected Atik device handle.
x	pointer to an integer which will be set to the X binning value.
y	pointer to an integer which will be set to the Y binning value.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetColumnRepairCanFixColumns()

artfn int ArtemisGetColumnRepairCanFixColumns	(	ArtemisHandle	handle,
		bool *	value
	)

Retrieves whether column repair can be enabled.

Parameters

handle	the connected Atik device handle.
value	a pointer to a boolean which will be set to whether the column repair can be enabled or not.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetColumnRepairColumns()

artfn int ArtemisGetColumnRepairColumns	(	ArtemisHandle	handle,
		int *	nColumn,
		unsigned short *	columns
	)

Get the columns on which column repair post processing is performed.

Parameters

handle	the connected Atik device handle.
nColumn	a pointer to an integer which will be set to the length of the columns array.
columns	a pointer to a user-managed array of length 1000, which will be set to the column values.

See also: ARTEMISERROR, ArtemisSetColumnRepairColumns

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetColumnRepairFixColumns()

artfn int ArtemisGetColumnRepairFixColumns	(	ArtemisHandle	handle,
		bool *	value
	)

Retrieves whether column repair is enabled or not.

Parameters

handle	the connected Atik device handle.
value	a pointer to a boolean which will be set to whether the column repair is enabled or not.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetContinuousExposingMode()

artfn BOOL ArtemisGetContinuousExposingMode ( ArtemisHandle handle )

Retrieves whether continuous exposing is enabled for the device.

Parameters

handle the connected Atik device handle.

Returns: TRUE if continuous exposing mode is enabled, FALSE otherwise.

◆ ArtemisGetDarkMode()

artfn BOOL ArtemisGetDarkMode ( ArtemisHandle handle )

Retrieves whether dark mode is enabled for the device.

Parameters

handle the connected Atik device handle.

Returns: TRUE if continuous exposing mode is enabled, FALSE otherwise.

◆ ArtemisGetEightBitMode()

artfn int ArtemisGetEightBitMode	(	ArtemisHandle	handle,
		bool *	eightbit
	)

Retrieves whether 8-bit mode is enabled on the device.

Parameters

handle	the connected Atik device handle.
eightbit	pointer to a boolean, which will be set to whether the 8-bit mode is enabled.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetGain()

artfn int ArtemisGetGain	(	ArtemisHandle	handle,
		bool	isPreview,
		int *	gain,
		int *	offset
	)

Get the currently set gain and offset for the device. Note that Horizon/ACIS cameras need to use ArtemisCameraSpecificOptionGetData() to get the gain.

Parameters

handle	the connected Atik device handle.
isPreview	whether gain will be returned for preview mode or normal mode.
gain	pointer to an integer which will be set to the current gain.
offset	pointer to an integer which will be set to the current offset.

See also: ARTEMISERROR, ArtemisCameraSpecificOptionGetData()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetGpioInformation()

artfn int ArtemisGetGpioInformation	(	ArtemisHandle	handle,
		int *	lineCount,
		int *	lineValues
	)

Parameters

handle	the connected Atik device handle.
lineCount
lineValues

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetImageData()

artfn int ArtemisGetImageData	(	ArtemisHandle	handle,
		int *	x,
		int *	y,
		int *	w,
		int *	h,
		int *	binx,
		int *	biny
	)

Provides information about the latest acquired image.

Parameters

handle	the connected Atik device handle.
x	pointer to an integer which will be set to the subframe size in pixels, on the X axis.
y	pointer to an integer which will be set to the subframe size in pixels, on the Y axis.
w	pointer to an integer which will be set to the width of the image in pixels.
h	pointer to an integer which will be set to the height of the image in pixels.
binx	pointer to an integer which will be set to the horizontal binning used.
biny	pointer to an integer which will be set to the vertical binning used.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetLensAperture()

artfn int ArtemisGetLensAperture	(	ArtemisHandle	handle,
		int *	aperture
	)

Gets the current lens aperture value.

Parameters

handle	the connected Atik device handle.
aperture	a pointer to an integer which will be set to the current aperture.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, ARTEMIS_NOT_INITIALIZED if lens not initialised, or ARTEMISERROR enumeration on failure

◆ ArtemisGetLensFocus()

artfn int ArtemisGetLensFocus	(	ArtemisHandle	handle,
		int *	focus
	)

Gets the current lens focus value.

Parameters

handle	the connected Atik device handle.
focus	a pointer to an integer which will be set to the current lens focus value.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, ARTEMIS_NOT_INITIALIZED if lens not initialised, or ARTEMISERROR enumeration on failure

◆ ArtemisGetLensLimits()

artfn int ArtemisGetLensLimits	(	ArtemisHandle	handle,
		int *	apertureMin,
		int *	apertureMax,
		int *	focusMin,
		int *	focusMax
	)

Returns the lens numerical limits for the device.

Parameters

handle	the connected Atik device handle.
apertureMin	a pointer to an integer which will be set to the minimum aperture value.
apertureMax	a pointer to an integer which will be set to the maximum aperture value.
focusMin	a pointer to an integer which will be set to the minimum focus value.
focusMax	a pointer to an integer which will be set to the maximum focus value.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, ARTEMIS_NOT_INITIALIZED if lens not initialised, or ARTEMISERROR enumeration on failure

◆ ArtemisGetMaxBin()

artfn int ArtemisGetMaxBin	(	ArtemisHandle	handle,
		int *	x,
		int *	y
	)

Retrieves the maximum binning supported by the device.

Parameters

handle	the connected Atik device handle.
x	pointer to an integer which will be set to the maximum supported X binning value.
y	pointer to an integer which will be set to the maximum supported Y binning value.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetProcessing()

artfn int ArtemisGetProcessing ( ArtemisHandle handle )

Return which post processing flags are enabled for the device.

Parameters

handle the connected Atik device handle.

See also: ARTEMISPROCESSING

Returns: ARTEMISPROCESSING enumeration of flags enabled for the device.

◆ ArtemisGetShutterSpeed()

artfn int ArtemisGetShutterSpeed	(	ArtemisHandle	handle,
		int *	speed
	)

Gets the shutter speed.

Parameters

handle	the connected Atik device handle.
speed	a pointer to an integer which will be set to the speed of the shutter.

See also: ARTEMISERROR, ArtemisCanSetShutterSpeed(), ArtemisSetShutterSpeed()

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_FUNCTION if the shutter speed is not supported for the device, or ARTEMISERROR enumeration on failure

◆ ArtemisGetSubframe()

artfn int ArtemisGetSubframe	(	ArtemisHandle	handle,
		int *	x,
		int *	y,
		int *	w,
		int *	h
	)

Retrieves the current subframing setting for the device.

Parameters

handle	the connected Atik device handle.
x	pointer to an integer which will be set to the current subframing X offset.
y	pointer to an integer which will be set to the current subframing Y offset.
w	pointer to an integer which will be set to the current subframing width.
h	pointer to an integer which will be set to the current subframing height.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGetWindowHeaterPower()

artfn int ArtemisGetWindowHeaterPower	(	ArtemisHandle	handle,
		int *	windowHeaterPower
	)

Gets the window heater power.

Parameters

handle	the connected Atik device handle.
windowHeaterPower	a pointer to an integer, which will be set to the current window heater power, between 0 and 255.

See also: ARTEMISERROR, ArtemisSetWindowHeaterPower()

Returns: ARTEMIS_OK on success, ARTEMARTEMIS_INVALID_PARAMETER if the device does not have a window heater, or ARTEMISERROR enumeration on failure

◆ ArtemisGuide()

artfn int ArtemisGuide	(	ArtemisHandle	handle,
		int	axis
	)

Parameters

handle	the connected Atik device handle.
axis	1= North 2= South 3= East 4= West

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisGuidePort()

artfn int ArtemisGuidePort	(	ArtemisHandle	handle,
		int	nibble
	)

Parameters

handle	the connected Atik device handle.
nibble	0b0001= North 0b0010= South 0b0100=East 0b1000=West

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisHasCameraSpecificOption()

artfn bool ArtemisHasCameraSpecificOption	(	ArtemisHandle	handle,
		unsigned short	id
	)

Returns whether the specified option is available.

Parameters

handle	the connected Atik device handle.
id	the camera specific option

See also: CameraSpecificOptionsIDs

Returns: true if supported, false if not.

◆ ArtemisHasFastMode()

artfn BOOL ArtemisHasFastMode ( ArtemisHandle handle )

Gets whether the device supports fast mode.

Parameters

handle the connected Atik device handle.

Returns: TRUE if fast mode is supported, FALSE if not

◆ ArtemisImageBuffer()

artfn void* ArtemisImageBuffer ( ArtemisHandle handle )

Returns a pointer to the internal image buffer which contains the latest captured image. The buffer size can be calculated by width * height * pixel depth.

Parameters

handle the connected Atik device handle.

See also: ArtemisGetImageData()

Returns: a pointer to the internal image buffer

◆ ArtemisImageReady()

artfn BOOL ArtemisImageReady ( ArtemisHandle handle )

Returns whether the image has been fully downloaded and is ready to access. This method can be polled until it returns TRUE, after which ArtemisGetImageData() and ArtemisImageBuffer() can be called to get the results of the exposure. It is recommended to add a delay in between polling (E.G. 10 milliseconds).

Parameters

handle the connected Atik device handle.

Returns: TRUE if the image is ready, FALSE on failure

◆ ArtemisInitializeLens()

artfn int ArtemisInitializeLens ( ArtemisHandle handle )

Initialise lens controls. If not called, lens control methods will return ARTEMIS_NOT_INITIALIZED.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisIsConnected()

artfn BOOL ArtemisIsConnected ( ArtemisHandle handle )

Returns whether the handle is currently connected to a camera.

Parameters

handle The device handle

Returns: TRUE if the handle is connected, FALSE otherwise

◆ ArtemisIsLocalConnection()

artfn BOOL ArtemisIsLocalConnection ( )

Gets whether the connection to the camera is local.

Returns: True if the connection is local (E.G. through an USB cable), false otherwise

◆ ArtemisLastExposureDuration()

artfn float ArtemisLastExposureDuration ( ArtemisHandle handle )

Returns the duration of the last exposure as floating point number of seconds.

Parameters

handle the connected Atik device handle.

Returns: the duration of the last exposure as floating point number of seconds.

◆ ArtemisLastStartTime()

artfn char* ArtemisLastStartTime ( ArtemisHandle handle )

Returns a pointer to the formatted last exposure start time. The buffer is internal to the SDK and is overwritten every time this function is called. Does not include milliseconds.

Parameters

handle the connected Atik device handle.

See also: ArtemisLastStartTimeMilliseconds()

Returns: pointer to a null terminated buffer containing the formatted time exposure was started at.

◆ ArtemisLastStartTimeMilliseconds()

artfn int ArtemisLastStartTimeMilliseconds ( ArtemisHandle handle )

Returns the last exposure start time millisecond component.

Parameters

handle the connected Atik device handle.

See also: ArtemisLastStartTime

Returns: millisecond component of the last exposure time.

◆ ArtemisLoadDLL()

artfn bool ArtemisLoadDLL ( const char * fileName )

Dynamically loads the Atik implementation DLL. This method is only needed if the DLL is linked dynamically. This method is part of the DLL example code.

Parameters

fileName the DLL's file path

See also: ArtemisUnLoadDLL()

Returns: Returns true if the dll could be loaded, false otherwise.

◆ ArtemisOpenShutter()

artfn int ArtemisOpenShutter ( ArtemisHandle handle )

Opens the shutter on the device. Please call ArtemisCanControlShutter() to see if the shutter can be controlled.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR, ArtemisCanControlShutter()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisOverlappedExposureValid()

artfn BOOL ArtemisOverlappedExposureValid ( ArtemisHandle handle )

Returns whether the overlapped exposure is still valid.

Parameters

handle the connected Atik device handle.

Returns: TRUE if valid, FALSE otherwise.

◆ ArtemisPrechargeMode()

artfn int ArtemisPrechargeMode	(	ArtemisHandle	handle,
		int	mode
	)

Sets the precharge mode of the camera. Precharge applies an in-camera offset, mainly for astronomy use.

Parameters

handle	the connected Atik device handle.
mode	ARTEMISPRECHARGEMODE enumeration value

See also: ARTEMISPRECHARGEMODE, ARTEMISERROR

Returns: ARTEMIS_OK on success, other ARTEMISERROR on error

◆ ArtemisProperties()

artfn int ArtemisProperties	(	ArtemisHandle	handle,
		struct ARTEMISPROPERTIES *	pProp
	)

Gets the connected camera's physical properties.

Parameters

handle	The connected camera's handle.
pProp	if successful, a pointer to a user provided ARTEMISPROPERTIES instance.

See also: ARTEMISERROR, ARTEMISPROPERTIES

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisPulseGuide()

artfn int ArtemisPulseGuide	(	ArtemisHandle	handle,
		int	axis,
		int	milli
	)

Parameters

handle	the connected Atik device handle.
axis	1= North 2= South 3= East 4= West
milli	number of milliseconds to pulse for on the selected axis

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisReadFromEEPROM()

artfn int ArtemisReadFromEEPROM	(	ArtemisHandle	handle,
		char *	password,
		int	address,
		int	length,
		unsigned char *	data
	)

Reads a value from the EEPROM. This API is for internal use.

Parameters

handle	the connected Atik device handle.
password	password required to interact with the device.
address	address of EEPROM
length	length of the data
data	pointer to the buffer containing the data

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisRefreshDevicesCount()

artfn int ArtemisRefreshDevicesCount ( )

Updates the available device count.

Returns

See also: ArtemisDeviceCount()

◆ ArtemisSetAmplifierSwitched()

artfn int ArtemisSetAmplifierSwitched	(	ArtemisHandle	handle,
		bool	bSwitched
	)

Enable/disable the device's amplifier. This function is equivalent to ArtemisAmplifier().

Parameters

handle	the connected Atik device handle.
bSwitched	whether to enable switching amplifier or not

See also: ARTEMISERROR, ArtemisAmplifier()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetAtikAir()

artfn void ArtemisSetAtikAir	(	const char *	host,
		int	port
	)

Connect to an AtikAir instance.

Parameters

host	The hostname or ip address of the instance, E.G. "192.168.0.1"
port	the port of the instance.

◆ ArtemisSetColumnRepairColumns()

artfn int ArtemisSetColumnRepairColumns	(	ArtemisHandle	handle,
		int	nColumn,
		unsigned short *	columns
	)

Set the columns on which column repair post processing is performed.

Parameters

handle	the connected Atik device handle.
nColumn	the length of the array of column indices provided in columns.
columns	an array of column indices to perform repair to.

See also: ARTEMISERROR, ArtemisGetColumnRepairColumns

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetColumnRepairFixColumns()

artfn int ArtemisSetColumnRepairFixColumns	(	ArtemisHandle	handle,
		bool	value
	)

Sets whether column repair is enabled.

Parameters

handle	the connected Atik device handle.
value	whether column repair is enabled or not.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetContinuousExposingMode()

artfn int ArtemisSetContinuousExposingMode	(	ArtemisHandle	handle,
		bool	bEnable
	)

Set whether continuous exposing mode is enabled. This only has an effect on supported devices.

Parameters

handle	the connected Atik device handle.
bEnable

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetCooling()

artfn int ArtemisSetCooling	(	ArtemisHandle	handle,
		int	setpoint
	)

Sets the cooling target temperature of the device. This will override ArtemisSetCoolingPower().

Parameters

handle	the connected Atik device handle.
setpoint	the target temperature of the device in hundreds of degrees celsius.

See also: ARTEMISERROR, ArtemisSetCoolingPower()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetCoolingPower()

artfn int ArtemisSetCoolingPower	(	ArtemisHandle	handle,
		int	power
	)

Sets the cooling power of the cooler directly. This will override ArtemisSetCooling().

Parameters

handle	the connected Atik device handle.
power	the power level of the cooler, from 0 to 255.

See also: ARTEMISERROR, ArtemisSetCooling()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetDarkMode()

artfn int ArtemisSetDarkMode	(	ArtemisHandle	handle,
		bool	bEnable
	)

Sets whether dark mode is enabled for the device.

Parameters

handle	the connected Atik device handle.
bEnable	whether to enable or disable dark mode.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetDebugCallback()

artfn void ArtemisSetDebugCallback ( void(*)(const char *message) callback )

Provide a pointer to a function, which will be invoked when debug output is produced. This can be used in combination with ArtemisAllowDebugToConsole.

Parameters

callback A function pointer to a compatible log function.

See also: ArtemisAllowDebugToConsole, ArtemisAllowDebugCallbackContext()

◆ ArtemisSetDebugCallbackContext()

artfn void ArtemisSetDebugCallbackContext	(	void *	context,
		void()(void context, const char *message)	callback
	)

Same as ArtemisSetDebugCallback(), but allows to pass an additional void pointer. This can be used to store a user-allocated data structure which will be passed to the callback. This pointer needs to be allocated and managed by the user. The context will never be freed by the API.

Parameters

context	The user-allocated pointer.
callback	A function pointer to a compatible log function

See also: ArtemisSetDebugCallback(), ArtemisAllowDebugToConsole()

◆ ArtemisSetFastCallback()

artfn BOOL ArtemisSetFastCallback	(	ArtemisHandle	handle,
		void()(ArtemisHandle handle, int x, int y, int w, int h, int binx, int biny, void imageBuffer)	callback
	)

Set the callback that will be invoked when a fast mode exposure is completed.

Parameters

handle	the connected Atik device handle.
callback	a pointer to a function which will be invoked when fast mode is completed.

Returns: TRUE on success, FALSE on failure.

◆ ArtemisSetFirmwareDir()

artfn void ArtemisSetFirmwareDir ( const char * firmwareDir )

Internal function used during flashing.

Parameters

firmwareDir The firmware directory as null terminated string.

◆ ArtemisSetGain()

artfn int ArtemisSetGain	(	ArtemisHandle	handle,
		bool	isPreview,
		int	gain,
		int	offset
	)

Set the gain and offset for the device Note that Horizon/ACIS cameras need to use ArtemisCameraSpecificOptionSetData() to set the gain.

Parameters

handle	the connected Atik device handle.
isPreview	whether to set gain for preview mode or normal mode.
gain	the gain to set (scale of 1-24).
offset	the offset to set.

See also: ARTEMISERROR, ArtemisCameraSpecificOptionSetData()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetGpioDirection()

artfn int ArtemisSetGpioDirection	(	ArtemisHandle	handle,
		int	directionMask
	)

Parameters

handle
directionMask

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetGpioValues()

artfn int ArtemisSetGpioValues	(	ArtemisHandle	handle,
		int	lineValues
	)

Parameters

handle	the connected Atik device handle.
lineValues

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetLensAperture()

artfn int ArtemisSetLensAperture	(	ArtemisHandle	handle,
		int	aperture
	)

Sets the lens aperture.

Parameters

handle	the connected Atik device handle.
aperture	the aperture to set

See also: ARTEMISERROR, ArtemisGetLensLimits()

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_PARAMETER if value out of limits, ARTEMIS_NOT_INITIALIZED if lens not initialised, or ARTEMISERROR enumeration on failure

◆ ArtemisSetLensFocus()

artfn int ArtemisSetLensFocus	(	ArtemisHandle	handle,
		int	focus
	)

Sets the lens focus.

Parameters

handle	the connected Atik device handle.
focus	the focus value to set

See also: ARTEMISERROR, ArtemisGetLensLimits()

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_PARAMETER if value out of limits, ARTEMIS_NOT_INITIALIZED if lens not initialised, or ARTEMISERROR enumeration on failure

◆ ArtemisSetOverlappedExposureTime()

artfn int ArtemisSetOverlappedExposureTime	(	ArtemisHandle	handle,
		float	fSeconds
	)

Set the overlapped exposure time.

Parameters

handle	the connected Atik device handle.
fSeconds	the time as a floating point number of seconds.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetPreview()

artfn int ArtemisSetPreview	(	ArtemisHandle	handle,
		bool	bPrev
	)

Sets whether preview mode is enabled for the device. If preview mode is enabled, the sensor is not cleared between exposures. Using preview mode, there might be more noise/glow in the resulting image.

Parameters

handle	the connected Atik device handle.
bPrev	whether to enable or disable preview mode.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetProcessing()

artfn int ArtemisSetProcessing	(	ArtemisHandle	handle,
		int	options
	)

Sets which post processing effects are enabled for the device.

Parameters

handle	the connected Atik device handle.
options	ARTEMISPROCESSING enumeration of post processing flags to enable for the device.

See also: ARTEMISERROR, ARTEMISPROCESSING

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetShutterSpeed()

artfn int ArtemisSetShutterSpeed	(	ArtemisHandle	handle,
		int	speed
	)

Sets the shutter speed.

Parameters

handle	the connected Atik device handle.
speed	the speed to set, between 1 and 200.

See also: ARTEMISERROR, ArtemisCanSetShutterSpeed(), ArtemisGetShutterSpeed()

Returns: ARTEMIS_OK on success, ARTEMIS_INVALID_FUNCTION if the shutter speed is not supported for the device, or ARTEMISERROR enumeration on failure

◆ ArtemisSetSubSample()

artfn int ArtemisSetSubSample	(	ArtemisHandle	handle,
		bool	bSub
	)

Set whether subsampling mode is enabled on the device.

Parameters

handle	the connected Atik device handle.
bSub

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSetWindowHeaterPower()

artfn int ArtemisSetWindowHeaterPower	(	ArtemisHandle	handle,
		int	windowHeaterPower
	)

Sets the window heater power.

Parameters

handle	the connected Atik device handle
windowHeaterPower	A value between 0 and 255 specifying the power to the window heater.

See also: ARTEMISERROR, ArtemisGetWindowHeaterPower()

Returns: ARTEMIS_OK on success, ARTEMARTEMIS_INVALID_PARAMETER if the device does not have a window heater, or ARTEMISERROR enumeration on failure

◆ ArtemisStartExposure()

artfn int ArtemisStartExposure	(	ArtemisHandle	handle,
		float	seconds
	)

Begin an exposure for the device, specifying a duration as floating point seconds.

Parameters

handle	the connected Atik device handle.
seconds	the seconds to perform the exposure for, as a floating point number.

See also: ARTEMISERROR, ArtemisStartExposureMS(), ArtemisAbortExposure()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisStartExposureMS()

artfn int ArtemisStartExposureMS	(	ArtemisHandle	handle,
		int	ms
	)

Begin an exposure for the device, specifying a duration as milliseconds.

Parameters

handle	the connected Atik device handle.
ms	the exposure duration in milliseconds.

See also: ARTEMISERROR, ArtemisStartExposure(), ArtemisAbortExposure()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisStartFastExposure()

artfn BOOL ArtemisStartFastExposure	(	ArtemisHandle	handle,
		int	ms
	)

Begins a fast mode exposure.

Parameters

handle	the connected Atik device handle.
ms	the exposure duration in milliseconds.

Returns: TRUE if started successfully, FALSE if not.

◆ ArtemisStartOverlappedExposure()

artfn int ArtemisStartOverlappedExposure ( ArtemisHandle handle )

Begin an overlapped exposure.

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisStopExposure()

artfn int ArtemisStopExposure ( ArtemisHandle handle )

Stop the current exposure for the device. This is analogous to ArtemisAbortExposure().

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR, ArtemisStartExposure(), ArtemisStartExposureMS(), ArtemisAbortExposure()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisStopGuiding()

artfn int ArtemisStopGuiding ( ArtemisHandle handle )

Parameters

handle the connected Atik device handle.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisStopGuidingBeforeDownload()

artfn int ArtemisStopGuidingBeforeDownload	(	ArtemisHandle	handle,
		bool	bEnable
	)

Parameters

handle	the connected Atik device handle.
bEnable

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSubframe()

artfn int ArtemisSubframe	(	ArtemisHandle	handle,
		int	x,
		int	y,
		int	w,
		int	h
	)

Set the device's subframe position and size. This is equivalent to calling ArtemisSubframePos() followed by ArtemisSubframeSize().

Parameters

handle	the connected camera's handle
x	the X offset of the subframe region.
y	the Y offset of the subframe region.
w	the width of the subframe region.
h	the height of the subframe region.

See also: ARTEMISERROR, ArtemisSubframePos(), ArtemisSubframeSize()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSubframePos()

artfn int ArtemisSubframePos	(	ArtemisHandle	handle,
		int	x,
		int	y
	)

Sets the device's subframe position.

Parameters

handle	the connected Atik device handle.
x	the X offset of the subframe region.
y	the Y offset of the subframe region.

See also: ARTEMISERROR, ArtemisSubframe()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisSubframeSize()

artfn int ArtemisSubframeSize	(	ArtemisHandle	handle,
		int	w,
		int	h
	)

Sets the device's subframe width and height.

Parameters

handle	the connected Atik device handle.
w	the width of the subframe region.
h	the height of the subframe region.

See also: ARTEMISERROR, ArtemisSubframe()

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisTemperatureSensorInfo()

artfn int ArtemisTemperatureSensorInfo	(	ArtemisHandle	handle,
		int	sensor,
		int *	temperature
	)

Gets temperature of the device for the specific sensor index, in hundreds of degrees centigrade. If "sensor" is set to 0, this will be set to the number of temperature sensors on the device.

Parameters

handle	the connected Atik device handle.
sensor	the index of the sensor to obtain information from.
temperature	a pointer to an integer which will be set to the temperature in tenths of degrees celsius, or the number of temperature sensors on the device.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisTriggeredExposure()

artfn int ArtemisTriggeredExposure	(	ArtemisHandle	handle,
		bool	bAwaitTrigger
	)

Sets whether the device will await a triggered exposure.

Parameters

handle	the connected Atik device handle.
bAwaitTrigger	whether to await a triggered exposure

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisUnLoadDLL()

artfn void ArtemisUnLoadDLL ( )

Unloads the Atik DLL and frees the internal DLL handle. This method is only needed if the DLL is linked dynamically. This method is part of the DLL example code.

See also: ArtemisLoadDLL()

◆ ArtemisUploadFirmware()

artfn int ArtemisUploadFirmware	(	ArtemisHandle	handle,
		char *	fileName,
		char *	password
	)

Upload a new firmware on the device. This API is for internal use.

Parameters

handle	the connected Atik device handle.
fileName	the firmware file's full path.
password	the password needed to enable upload.

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

◆ ArtemisWriteToEEPROM()

artfn int ArtemisWriteToEEPROM	(	ArtemisHandle	handle,
		char *	password,
		int	address,
		int	length,
		const unsigned char *	data
	)

Writes a value to the EEPROM. This API is for internal use.

Parameters

handle	the connected Atik device handle.
password	password required to interact with the device.
address	address of EEPROM
length	length of the data
data	pointer to the buffer containing the data

See also: ARTEMISERROR

Returns: ARTEMIS_OK on success, or ARTEMISERROR enumeration on failure

Classes

Macros

Typedefs

Enumerations

Functions

Variables

Detailed Description

Typedef Documentation

◆ ArtemisHandle

Enumeration Type Documentation

◆ ARTEMISCAMERASTATE

◆ ARTEMISCOLOURTYPE

◆ ARTEMISCOOLINGINFO

◆ ARTEMISEFWTYPE

◆ ARTEMISERROR

◆ ARTEMISPRECHARGEMODE

◆ ARTEMISPROCESSING

◆ ARTEMISPROPERTIESCAMERAFLAGS

◆ ARTEMISPROPERTIESCCDFLAGS

◆ CameraSpecificOptionsIDs

Function Documentation

◆ ArtemisAbortExposure()

◆ ArtemisAdvancedHotPixelRemoval()

◆ ArtemisAllowDebugToConsole()

◆ ArtemisAmplifier()

◆ ArtemisAPIVersion()

◆ ArtemisAutoAdjustBlackLevel()

◆ ArtemisAutoHotPixelRemoval()

◆ ArtemisBin()

◆ ArtemisCameraConnectionState()

◆ ArtemisCameraSerial()

◆ ArtemisCameraSpecificOptionGetData()

◆ ArtemisCameraSpecificOptionSetData()

◆ ArtemisCameraState()

◆ ArtemisCanControlShutter()

◆ ArtemisCanInteractWithEEPROM()

◆ ArtemisCanSetShutterSpeed()

◆ ArtemisCanUploadFirmware()

◆ ArtemisClearColumnRepairColumns()

◆ ArtemisClearVReg()

◆ ArtemisCloseShutter()

◆ ArtemisColourProperties()

◆ ArtemisConnect()

◆ ArtemisContinuousExposingModeSupported()

◆ ArtemisCoolerWarmUp()

◆ ArtemisCoolingInfo()

◆ ArtemisDeviceCount()

◆ ArtemisDeviceHasFilterWheel()

◆ ArtemisDeviceHasGuidePort()

◆ ArtemisDeviceInUse()

◆ ArtemisDeviceIsCamera()

◆ ArtemisDeviceIsPresent()

◆ ArtemisDeviceName()

◆ ArtemisDevicePresent()

◆ ArtemisDeviceSerial()

◆ ArtemisDisconnect()

◆ ArtemisDLLVersion()

◆ ArtemisDownloadPercent()

◆ ArtemisEFWConnect()

◆ ArtemisEFWDisconnect()

◆ ArtemisEFWGetDetails()

◆ ArtemisEFWGetDeviceDetails()

◆ ArtemisEFWGetPosition()

◆ ArtemisEFWIsConnected()

◆ ArtemisEFWIsPresent()

◆ ArtemisEFWNmrPosition()

◆ ArtemisEFWSetPosition()

◆ ArtemisEightBitMode()

◆ ArtemisExposureTimeRemaining()

◆ ArtemisFilterWheelInfo()

◆ ArtemisFilterWheelMove()

◆ ArtemisGetAmplifierSwitched()

◆ ArtemisGetBin()

◆ ArtemisGetColumnRepairCanFixColumns()

◆ ArtemisGetColumnRepairColumns()

◆ ArtemisGetColumnRepairFixColumns()

◆ ArtemisGetContinuousExposingMode()

◆ ArtemisGetDarkMode()

◆ ArtemisGetEightBitMode()

◆ ArtemisGetGain()
